CEM DT-351 Compact AC, AC/DC Autoranging Clamp Meter (AC/DC-400A/600V)

  • Manufacturer:CEM
    Model: DT-351
    Guarantee: 12 Month
  • Contact
  •  Call for best price

     Hanoi city: (024) 35.381.269

     Danang city: (0236) 374.77.11

     HCM city: (028) 38.119.636

Function: Max Range -  Basic Accuracy

Voltage DC: 600V  ;  ±(0.5%+1d)

Voltage AC: 600V  ;  ±(1.5%+2d)

Current DC: 400A  ;  ±(2.0%+5d)

Current AC: 400A  ;  ±(2.5%+4d)

Resistance: 40MΩ  ;  ±(3.0%+5d)

Temperature: 760ºC/ 1400ºF  ;  ±(3.0%+3d)

Capacitance: 100uF  ;  ±(2.5%+5d)

Frequency: 10kHz  ;  ±(1.2%+2d)

Continuity check: Buzzer sounds at 50Ω

Diode test: Test current 0.3mA

Size (H x W x D): 198mm x 66mm x 36mm

Weight: 230g


Accessories: Test leads, gift box with carrying case, Temperature probe and Two“AAA”1.5V batteries.


Detail

Datasheet


Features

DT-350

DT-351

DT-352

DT-353

Current measurement

AC

AC/DC

AC

AC/DC

LCD display counts

4000

4000

2000

50000

Data Hold

*

*

*

*

REL (Zero) Function

*

*

*

Auto Power Off

*

*

*

*

Low battery indication

*

*

*

*

1.2” (30mm) Jaw opening

*

*

*

*

NCV Detection

*

*

*

*




Specifications

Function

Max Range

Basic Accuracy

DT-350

DT-351

DT-352

DT-353

Voltage DC

600V

±(0.5%+1d)

*

*

*

*

Voltage AC

600V

±(1.5%+2d)

*

*

*

*

Current DC

400A

±(2.0%+5d)

*

*

Current AC

400A

±(2.5%+4d)

*

*

*

*

Resistance

40MΩ

±(3.0%+5d)

*

*

*

*

Temperature

760ºC/ 1400ºF

±(3.0%+3d)

*

*

*

*

Capacitance

100uF

±(2.5%+5d)

*

*

10mF

Frequency

10MHz

±(1.2%+2d)

*

10kHz

*

Continuity check

Buzzer sounds at 50Ω

Diode test

Test current 0.3mA
