Measuring Range: 0.05 to 80m (0.15ft to 262ft)
Measuring Accuracy: Typically ±1.5mm (±0.06in)
Smallest Unit Displayed: 1mm
Measuring Units: m, in, ft
Laser Class: Class II 635nm, <1mW
Tilt Sensor Measuring Range: ±65°
Tilt Sensor Measuring Accuracy: ±0.5°
Dust Protect/Splash Proof: IP54
History Measurement Records: 99
Keyboard Type: Super Soft-touch (Long Life)
Operating Temperature: -10℃ to 50℃ (14℉ to 122℉)
Storage Temperature: -20℃ to 70℃ (4℉ to 158℉)
Battery Life: Up to 4,000 Measurements
Battery: Type AA 2x1.5V
Auto Laser Switch-off: After 0.5min
Auto Instrument Switch-off: After 3min
Size(HxWxD): 115mm x 54mm x 32mm
Weight: 145g
Accessories:
2 x 1.5V AAA batteries and gift box with carrying case.
Datasheet
Features | |||
| iLDM-35S | iLDM-65S | iLDM-80S |
Area, Volume Calculations | * | * | * |
Indirect measurement using Pythagoras | * | * | * |
Angle measurement using tilt sensor(± 90°) | * | * | |
Addition/Subtraction | * | * | * |
Continuous Measurement | * | * | * |
Min/Max Distance Tracking | * | * | * |
Display illumination and 4-line display. | * | * | * |
Buzzer indication | * | * | * |
Bluetooth interface | * | * | * |
