AC Output Rating
- Maximum power: 1500VA
- Power per phase: 500VA
Voltage (per phase)
- Voltage range: 150V / 300V
- Accuracy: 0.2%+0.2%F.S.
- Resolution: 0.1V
- Distortion
+ 0.3% @ 50/60Hz
+ 1.5% @ 15 to 1.2kHz
- Line regulation: 0.1%
- Load regulation: 0.2%
- Temperature coefficient: 0.02% per degree from 25˚C
Maximum Current (per phase)
- RMS 4A/2A
- Peak 24A/12A
Frequency
- Frequency range: DC, 15 to 1.2kHz
- Accuracy: 0.15%
Phase Angle
- Phase angle range: 0 to 360˚
- Resolution: 0.1˚
- Accuracy: < 0.8˚ @ 50/60Hz
DC Output Rating (per phase)
- Power: 250W
- Voltage: 212V/424V
- Current: 2A/1A
Three-phase Input Voltage (per phase)
- Operating range
+ 3Ø 100 to 240V±10%VLN (WYE)
+ 3Ø 100 to 240V±10%VLL (Delta)
- Frequency range: 47 to 63Hz
- Maximum current: 9A
- Power factor: 0.97 Min
Measurement
Voltage (Line-Neutral)
- Voltage range: 150V/300V
- Voltage accuracy: 0.2%+0.2%F.S.
- Resolution: 0.1V
Current (per phase)
- Range (Peak): 24A
- Current accuracy (RMS): 0.4%+0.3%F.S.
- Current accuracy (Peak): 0.4%+0.6%F.S.
- Current resolution: 0.01A
Power (per phase)
- Accuracy: 0.4%+0.4% F.S.
- Resolution: 0.1W
Other Specifications
- Efficiency: 68%
- Protection: UVP, OCP, OPP, OTP, FAN
Temperature Range
- Operating: 0˚C to 40˚C
- Storage: -40˚C to 85˚C
- Humidity: 30% to 90%
Safety & EMC: CE
Dimensions (H x W x D): 400 x 482.6 x 600.5 mm
Weight: 75 kg
