Width: 50.8 mm (2 in)
Height: 30.5 mm (1.201 in)
Length: 76.2 mm (3 in)
Industry: Medical
Approvals: IEC/EN60335-1
Compliance: IEC/EN60335-1
Efficiency: 93 %
Unit Weight: 135 g
Output Power: 130 W
Input Voltage: 80 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Power - Convection: 100 W
Power - Forced Air: 130 W
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 5.4 A
Output Voltage-Channel 1: 24 VDC
Operating Temperature Range: - 30 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 30 C
