Width: 25.4 mm (1 in)
Height: 10.2 mm (0.402 in)
Length: 50.8 mm (2 in)
Industry: Industrial
Dimensions: 50.8 mm x 25.4 mm x 10.2 mm
Efficiency: 81 %
Unit Weight: 32.500 g
Output Power: 7.5 W
Input Voltage: 18 V to 36 V
Cooling Method: Convection
Mounting Style: Through Hole
Mechanical Style: Isolated
Isolation Voltage: 1.5 kV
Number of Outputs: 2 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 18 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 310 mA
Output Current-Channel 2: 310 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 71 C
Minimum Operating Temperature: - 25 C
