Width: 51 mm
Height: 22.5 mm
Length: 110 mm
Region: Universal
Industry: Medical, Industrial
Approvals: CE, cUL, EN60950-1, GS, IEC60950-1, UL60950-1
Compliance: PSE
Efficiency: Level VI
Output Power: 36 W
Input Voltage: 90 VAC to 264 VAC
Connector Type: Barrel Connector
Cooling Method: Convection
Mounting Style: Desktop
Load Regulation: Regulated
Mechanical Style: External
Center Pin Length: 12 mm
Isolation Voltage: 4.24 kVDC
Number of Outputs: 1 Output
DC Output Connector: 2.1 mm Barrel Plug (2.1x5.5)
Input Voltage - Max: 264 VAC
Input Voltage - Min: 90 VAC
Connector A Polarity: Center Positive
DC Output Cord Length: 1.8 m
Output Current-Channel 1: 2 A
Output Voltage-Channel 1: 18 VDC
AC Plug included/required: Required
Operating Temperature Range: - 20 C to + 60 C
Maximum Operating Temperature: + 60 C
Minimum Operating Temperature: - 20 C
