Test space: 100 x 100 x 120 cm
Max Capacity: 20 kN (2 kg); 50 kN (5 kg)
Units
Force：gf, kgf, lbf, N, kN, ozf, tonf(SI), ton(long), tonf(short)
Pressure：Kpa, Mpa, psi, bar, mm-Aq, mm-Hg
Force Resolution: 23 bits
Force Precision: ±1% (with range 5~100% load cell capacity)
Stroke Resolution: 0.001mm
Speed Range: 2~200 mm/min
Speed Precision: ±1%
PC-Port: RJ45(TCP/IP) [Software is optional]
Data Sampling Rate: Max. 1200Hz
Motor: DC motor
Hardware Protection: Upper/ Lower limit, Emergency stop button
Power: Single Phase 220V, 10A
Dimension (WxDxH)：152 x 100 x 196 cm
Weight：840 kg
