Test range: 0.05 ～ 4.5kgf/c㎡ (500 ～ 45000mmH2O)
Pressurization Rate: 0.05 ～ 4.5kgf/c㎡/min(No setting stage but can be set on demand, but it can be set depend on demand).
Pressurization Display: bar、Mpa、kpa、kgf/c㎡、mbar、psi、mmH2O、cmH2O (8 types can be used depend on the demand).
Gripping Ring: Ø11.28 cm（100c㎡）(can be customized)
Pressure Sustaining: can be customized for the rate of pressure and duration of pressurization. Manually set for three-tiered pressurization.
Data Storage: Maximum for up to 50 data storage and can be transmitted by USB.
Force Supply: Pressure control can facilitate the precision of pressuring speed.
Sample Gripping: Air compressor can be adjusted by thickness of test specimens.
Gripping Force: Can reach 1500kg
Language: Chinese, English, Japanese.
7 Inch-Touch Screen: Easy operation. The curve diagram ensures the testing condition.
Dimension: 433 x 435.4 x 728.4mm
Weight：76kg
Power Supply: AC110V~AC220V
Precision Pressure Indicator: 0.001 bar
Pressure: Maximum for 50 minutes.
Feature:
1. Clear testing page, easy operation and pressurization is illustrated with the curve diagram.
2. Three-tiered rates of pressure changes, pressure levels and duration of the pressurization.
3. Multiple selections of the metric and imperial systems.
4. A full calibration system to ensure the precision of the pressure sensor and pressuring speed.
