Max.Capacity (kgf): 50
Rated output ( mV/V): 0.5 (approx)
Zero balance ( mV/V): 0±0.1
Combined error (%RO): 0.5
Repeatability (%RO): 0.1
Creep (30 min.) (%RO): 0.05
Temperature effect on: interference error: ± 3%FS
+ Zero value (%RO/10℃ ): 0.1
+ Output value (%RO/10℃ ): 0.6
Excitation
+ Recommend (V ): 10
+ Maximum ( V): 15
Resistance :
+ Input (Ω ): 400±50 / 800±50
+ Output ( Ω): 350±3.5 / 700±7
Insulation ( ㏁): ＞2000 @50VDC
Compensated temp.range (℃): -10~+40
Operating temp, ( ℃ ): -20~+70
