HiLo alarm — Audibly and visibly alerts when measurements exceed your specified limits: Yes
Min Scan - measurement rate of up to 20 readings per second with on-screen min and max for quick inspection over a large area
Statistics Mode — Instantly calculate average, standard deviation, min/max thickness and number of readings while measuring
A Scan - with adjustable Gain with screen capture for further analysis and documentation
B Scan - display in which a cross sectional profile of the test material is represented •
Graphics readout for detailed analysis of the coating system
Onscreen Batch Annotation — Add notes, change batch names and more with built-in
QWERTY keyboard •
Multiple stored calibration adjustments for measuring on a variety of substrate conditions
Connection Options: USB, Bluetooth, WIFI
Probe Type: UTG P; 15 MHz Single Element
Delay Line
Thru-Paint Capability: Yes
Steel Range: 0.008" to 0.475"; 0.2 mm to 12.0 mm
Plastic Range: 0.005" to 0.165"; 0.125 mm to 4.500 mm
Resolution: 0.001”, 0.01 mm
Accuracy: ±0.001”; ±0.03 mm
