Rated voltage（kV): 60
Rated current（mA): 2
Rated power（W): 120
Mass of the whole machine（kg): 9
Volume of the whole machine（mm³): 465*390*190
Height of the voltage doubling cylinder（mm): 440
Accuracy of the output voltage: ± (1.0% of the reading ± 2 digits)
Accuracy of the output current: ± (1.0% of the reading ± 2 digits)
Ripple coefficient: ≤0.5%
Working mode: It is for intermittent use, with a rated load duration of 30 minutes.
Overload capacity: The no-load voltage can exceed the rated voltage by 10% and be used for 10 minutes.
The maximum charging current is 1.25 times the rated current.
Power: AC220V±10% 50HZ
Working environment
Temperature: -10℃ to 40℃
Relative humidity: It should not be greater than 85% (without condensation) when the room temperature is 25℃.
Altitude: Below 1,500 meters
