Color: Black
Pitch: 4.19 mm (0.165 in)
Width: 20.22 mm
Gender: Receptacle (Female)
Height: 40.01 mm
Length: 43.69 mm
Material: Plastic
Dimensions: 20.22 mm x 40.01 mm x 43.69 mm
Insulation: Insulated
Application: Wire to Wire
Row Spacing: 7.11 mm
Unit Weight: 16.690 g
REACH - SVHC: Details
Mating Gender: Plug
Contact Gender: Without Pin Contacts
Current Rating: 7.5 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 250 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 20 AWG
Housing Material: Nylon
Wire Gauge Range: 16 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: DTM06-12SD-xxxx
Number of Positions: 12 Position
Attachment Hole Diameter: 1 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
