Color: Black
Pitch: 3 mm, 3.4 mm, 5.8 mm, 6.1 mm
Width: 82 mm
Gender: Receptacle (Female)
Length: 56 mm
Material: Plastic
Dimensions: 82 mm x 40 mm x 56 mm
Row Spacing: 10.85 mm x 11.35 mm x 3.5 mm
Unit Weight: 94.800 g
REACH - SVHC: Details
Contact Gender: Without Pin Contacts
Current Rating: 7.5 A, 13 A
Mounting Angle: Straight
Mounting Style: Panel Mount
Number of Rows: 4 Row
Voltage Rating: 48 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polybutylene Terephthalate (PBT)
Wire Gauge Range: 14 AWG to 20 AWG
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Number of Positions: 32 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
