Color: Black
Pitch: 3.81 mm, 4.7 mm, 6.71 mm
Width: 52.76 mm
Gender: Receptacle (Female)
Height: 66.19 mm
Length: 66.19 mm
Material: Plastic
Application: Wire to Wire
Unit Weight: 88 g
Contact Gender: Pin (Male)
Current Rating: 7.5 A, 13 A, 25 A
Mounting Angle: Straight
Mounting Style: Mounting Flange
Number of Rows: 6 Row
Voltage Rating: 250 VDC
Wire Gauge Max: 10 AWG
Wire Gauge Min: 22 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 22 AWG to 10 AWG
Locking Mechanism: Integrated in Housing
Ingress Protection: IP67
Number of Positions: 48 Position
Attachment Hole Diameter: 2.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
