DEUTSCH - TE Connectivity DT04-6P-KIT 6-Way DT04-6P AND WEG ONLY

Pitch: 9.12 mm (0.359 in)

Gender: Receptacle (Female)

Row Spacing: 4.45 mm

Unit Weight: 10.560 g

REACH - SVHC: Details

Mating Gender: Plug

Mounting Angle: Straight

Mounting Style: Cable Mount / Free Hanging

Number of Rows: 3 Row

Voltage Rating: 250 V

Wire Gauge Max: 14 AWG

Wire Gauge Min: 20 AWG

Housing Material: Polyamide (PA)

Wire Gauge Range: 14 AWG to 20 AWG

Termination Style: Crimp

Mating Part Number: DT06-6S

Number of Positions: 6 Position

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C
