Color: Brown
Pitch: 5.461 mm (0.215 in)
Width: 55.12 mm
Gender: Receptacle (Female)
Height: 35.48 mm
Length: 39.24 mm
Material: Plastic
Dimensions: 55.12 mm x 35.48 mm x 39.24 mm
Row Spacing: 21.34 mm
Unit Weight: 26 g
REACH - SVHC: Details
Mating Gender: Plug
Contact Gender: Pin (Male)
Current Rating: 13 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Wire Gauge Max: 16 AWG
Contact Plating: Tin
Housing Material: Polyamide (PA)
Wire Gauge Range: 16 AWG
Termination Style: Solder Pin
Mating Part Number: DT06-08SD
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
