Color: Black
Pitch: 4.19 mm (0.165 in)
Width: 15.24 mm
Gender: Plug (Male)
Height: 31.62 mm
Length: 30.1 mm
Material: Plastic
Dimensions: 15.24 mm x 31.62 mm x 30.1 mm
Application: Wire to Wire
Unit Weight: 9.750 g
REACH - SVHC: Details
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 7.5 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 250 V
Wire Gauge Max: 16 AWG
Wire Gauge Min: 22 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 16 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68, IP6K9K
Mating Part Number: DTM04-08PB
Number of Positions: 8 Position
Attachment Hole Diameter: 1 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
