Color: Black
Pitch: 6.71 mm (0.264 in)
Width: 26.92 mm
Gender: Receptacle (Female)
Height: 26.62 mm
Length: 47.27 mm
Material: Plastic
Dimensions: 26.92 mm x 26.62 mm x 47.27 mm
Insulation: Insulated
Application: Wire to Wire
Row Spacing: 10.16 mm
Unit Weight: 47 g
Mating Gender: Plug
Contact Gender: Without Pin Contacts
Current Rating: 25 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 2 Row
Voltage Rating: 200 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 14 AWG
Contact Plating: Nickel
Housing Material: Polyamide (PA)
Wire Gauge Range: 12 AWG to 14 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68
Mating Part Number: DTP06-4S-xxxx
Number of Positions: 4 Position
Attachment Hole Diameter: 2.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
