Color: Gray
Pitch: 6.71 mm (0.264 in)
Width: 18.59 mm
Gender: Plug (Male)
Height: 18.06 mm
Length: 34.65 mm
Material: Plastic
Dimensions: 18.59 mm x 18.06 mm x 34.65 mm
Insulation: Insulated
Application: Wire to Wire
Unit Weight: 8.680 g
Mating Gender: Receptacle
Contact Gender: Without Socket Contacts
Current Rating: 25 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Number of Rows: 1 Row
Voltage Rating: 200 V
Wire Gauge Max: 12 AWG
Wire Gauge Min: 14 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 12 AWG to 14 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP68
Mating Part Number: DTP04-2P
Number of Positions: 2 Position
Attachment Hole Diameter: 2.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
