Width: 50.8 mm
Gender: Receptacle (Female)
Height: 47.53 mm
Length: 68.5 mm
Material: Aluminum
Dimensions: 50.8 mm x 47.53 mm x 68.5 mm
Application: Wire to Wire
Unit Weight: 88.287 g
REACH - SVHC: Details
Contact Gender: Without Socket Contacts
Current Rating: 7.5 A, 13 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 14 AWG
Wire Gauge Min: 22 AWG
Housing Material: Aluminium
Wire Gauge Range: 22 AWG to 14 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: HD36-24-XXXX
Number of Positions: 47 Position
Attachment Hole Diameter: 1.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
