Width: 49.32 mm
Gender: Plug (Male)
Height: 49.32 mm
Length: 81.05 mm
Material: Aluminum
Dimensions: 49.32 mm x 49.32 mm x 81.05 mm
Application: Wire to Wire
Unit Weight: 146.609 g
REACH - SVHC: Details
Contact Gender: Without Socket Contacts
Current Rating: 13 A, 25 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 10 AWG
Wire Gauge Min: 20 AWG
Housing Material: Aluminium
Wire Gauge Range: 10 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: HD34-24-XXX
Number of Positions: 19 Position
Attachment Hole Diameter: 2.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
