Color: Black
Width: 50.8 mm
Gender: Plug (Male)
Height: 47.63 mm
Length: 58.67 mm
Material: Plastic
Dimensions: 50.8 mm x 47.63 mm x 58.67 mm
Application: Wire to Wire
Unit Weight: 51 g
REACH - SVHC: Details
Mating Gender: Plug
Accessory Type: Plug Housing
Contact Gender: Without Pin Contacts
Current Rating: 13 A, 25 A
Mounting Angle: Straight
Mounting Style: Panel Mount
Voltage Rating: 250 V
Wire Gauge Max: 10 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 10 AWG to 20 AWG
Locking Mechanism: Integrated in Housing
Termination Style: Crimp
Ingress Protection: IP67
Mating Part Number: HDP26-24-19
Flammability Rating: UL 94 V-1
Number of Positions: 19 Position
Attachment Hole Diameter: 2.5 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
