Color: Black
Width: 50.8 mm
Gender: Receptacle (Female)
Height: 47.63 mm
Length: 41.86 mm
Dimensions: 50.8 mm x 47.63 mm x 41.86 mm
Application: Wire to Wire
Unit Weight: 54.780 g
Mating Gender: Plug
Current Rating: 13 A, 100 A
Mounting Angle: Straight
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 250 V
Wire Gauge Max: 4 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 4 AWG
Locking Mechanism: Integrated in Housing
Ingress Protection: IP67
Mating Part Number: HDP26-24-7SX
Number of Positions: 7 Position
Attachment Hole Diameter: 6 mm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
