Pressure (T):50
Structure:Horizontal
Crush method:Horizontal
Chamber:Independent horizontal structure and control system
Test Space:W1000 X D1000 X H1000mm
Overall Dimensions:W3860 X D1230 X H2300mm
Power Supply:AC380V 50HZ
Crush speed:1~400mm/min（Adjustable）
Nail Penetration Speed:1~40mm/s
Test Method:Force and displacement (deformation), voltage, or a combination of these three
Control Method:Computer remote Control, force, displacement, total voltage or single voltage can be completed independently or combine as control variable ,the test will be stopped when any condition reaches the set value.
Drive Mode:Electro-hydraulic servo
Crush Accuracy:±0.5%
Nail Penetration Accuracy:±1mm/s
Crush Deformation:0~100% multi-gears set, multi-layer crush deformation loading available
Crush Fixture:Special-shaped crush head （300X150mm）， Flat crush plate ， Arc crush plate （Radius 75mm），fixtures in different size according to different standards
Data Acquisition Module:Independent remote collection and isolation ,Multiplex voltage, temperature, current acquisition channel, ensure the data correctly , Acquisition frequency 100HZ
Safety Alarm Device:Electrical leakage, over voltage, overload and over temperature, over current protection, abnormal sound and light alarm, smoke alarm lamp, etc
Safety Device:Video monitoring system, safety explosion protection system, smoke, smoke alarm devices, explosion-proof lighting, etc
Standard Configuration:Crush penetration test machine, computer control cabinet, control software, the voltage current temperature acquisition system, crush fixture, video monitoring system, fire extinguishing system, computer, etc. Each 1 set
