Width: 2.5 mm
Height: 1.5 mm
Length: 4.5 mm
Unit Weight: 52 mg
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 1 W
DC Current Gain hFE Max: 1000
Emitter- Base Voltage VEBO: 10 V
Collector- Base Voltage VCBO: 90 V
Continuous Collector Current: 500 mA
Maximum DC Collector Current: 500 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 65 C
DC Collector/Base Gain hfe Min: 1000 at 150 mA at 10 V, 2000 at 500 mA at 10 V
Collector- Emitter Voltage VCEO Max: 80 V
