Diotec Semiconductor DD300 Fast Recovery Rectifiers HV Diode, D2.5x6.5, 3000V, 0.02A, 150C
Manufacturer: Diotec Semiconductor Model: DD300 - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Unit Weight: 292 mg
Configuration: Single
Recovery Time: 150 ns
Mounting Style: Through Hole
Max Surge Current: 3 A
If - Forward Current: 20 mA
Ir - Reverse Current: 5 uA
Vf - Forward Voltage: 40 V
Vr - Reverse Voltage: 3 kV
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 50 C
