Mains Power Supply: Connection according to IEC/EN60320-1; C320
90 V – 264 V AC, 50 / 60 Hz, single-phase
Dimension (instrument): 560 x 221 x 355 mm/ 22 x 8.7 x 14 in
Weight: 15.1 kg/ 33.2 lbs
Internal voltage measurement:
Range: 0 - 75 V DC
Resolution: 0.1 V (or better)
Typical accuracy: ± 0.5% of reading ± 0.1 V
Internal current measurement:
Range: 0 - 400 A DC
Resolution: 0.1 A
Display range: 0 – 2 999.9 A DC
Basic accuracy: ± (0.5 % of reading + 0.1 A)
Resolution: 0.1 A
Load section:
Battery voltage: 5.55* – 70.5 V DC
Power: 19.2 kW (max)
Constant current range (Const I): 0 – 340 A DC*
Typical accuracy: ± (0.5 % of reading + 0.2 A)
Ripple: max 0.4 A peak
Resolution: 0.1 A
Constant resistance (Const R): 0.2 – 70.5 Ω
Typical accuracy: ± 1%
Resolution: up to 0.01 Ω
Constant power range (Const P): 0 – 19.2 kW*
Constant power resolution (Const P): 0.01 kW
Typical accuracy: ± 1%
Ripple: max 0.2 kW
Display Size: 5.7 inch color touch screen display
Environment conditions
• Operating temperature: -20 °C to +55 °C / -4 °F to +131 °F
• Storage & Transportation temperature: -40 °C to +70 °C / -40 °F to +158 °F
• Relative humidity: up to 95%, non-condensing
• Pollution degree: 2
