Weight: 1.35 kg
Deadband: 0.4 to 0.9 inH2O
Compliance: CSA, FM, UL
Switch Note: 1 form C relay (SPDT), 10 A, 120/240 VAC, 28 VDC. Resistive 50 mA, 125 VDC
Switch Type: SPDT NO/NC, Selectable
Pressure Type: Differential
Pressure, Max: 5.5 inH₂O
Pressure, Min: 1.4 inH₂O
Switch Rating: 10 A @ 120/240 Vac/28 Vdc; 50 mA @ 125 Vdc
Proof Pressure: Up to 45 inH2O
Supply Voltage: 24 Vdc
Materials, Wetted: Consult Factory
Supply Power Type: DC
Media Compatibility: Air, Argon, Butane, Carbon dioxide, Combustible Gases, Helium, Hydrogen, Methane, Nitrogen, Non-Corrosive Dry Gases, Oxygen, Propane
Mounting Orientation: Vertical Diaphragm
Set Point Adjustment: External Screw
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 140 °F
Operating Temperature, Min: 0 °F
