Weight: 3.9 kg
Accuracy: ± 0.075 %
Compliance: CE, FM
Damping Time: 0.25 to 60 s
Display Type: N/A
Accuracy Note: ± 0.075% FS (@ 20°C)
Output Detail: HART® Communication
Output Signal: Current, HART
Pressure Type: Differential
Pressure, Max: 750 inH₂O
Pressure, Min: 0 inH₂O
Response Time: 0.12 s
Burst Pressure: 10,000 psi Maximum
Proof Pressure: Up to 2000 psi
Supply Voltage: 11.9 to 45 Vdc
Turndown Ratio: 100:1
Loop Resistance: Operation: 0 to 1500 Ω, HART® Communication: 250 to 500 Ω
Thermal Effects: ± 0.125% span/32°C
Electrical Output: 4 to 20 mA, HART
Enclosure Ratings: Hazardous Location Rated, IP66, NEMA Type 4X
Materials, Wetted: 316L Stainless Steel, Fluoroelastomer
Supply Power Type: DC
Long Term Stability: ± 0.125% FSO/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Oxygen, Steam
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Process Temperature, Max: 120 °C
Process Temperature, Min: -40 °C
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -40 °C
