Weight: 2.5 kg
Accuracy: ± 0.075 %
Stability: ± 0.125% FSO/year
Compliance: CE, FM
Span Limit: 0.22 to 21 psi
Damping Time: 0.25 to 60 s
Display Type: LCD
Accuracy Note: ± 0.075% FS (@ 20°C)
Output Detail: 4 to 20 mA / HART Communication
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 3600 psi
Pressure, Min: 0 psi
Response Time: 0.12 s
Proof Pressure: Up to 58 psi
Supply Voltage: 11.9 to 45 Vdc
Turndown Ratio: 100:1
Loop Resistance: Operation: 0 to 1500 Ω, HART® Communication: 250 to 500 Ω
Thermal Effects: ± 0.125% span/32°C
Number of Digits: 5
Enclosure Ratings: Hazardous Location Rated, IP66, NEMA Type 4X
Materials, Wetted: 316L Stainless Steel
Supply Power Type: DC
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Process Connection Size: 1/2 in
Process Connection Type: NPT Female
Process Temperature, Max: 248 °F
Process Temperature, Min: -40 °F
Operating Temperature, Max: 176 °F
Operating Temperature, Min: -22 °F
