Weight: 811 g
Accuracy: Electrical: ± 0.5 %, Mechanical: ± 2 %
Dial Dia: 4 in
Compliance: CE
Dial Depth: 68 mm
Display Type: N/A
Accuracy Note: Electrical: ± 4%, Mechanical: ± 4% (includes linearity, hysteresis, repeatability)
Mounting Note: Vertical Diaphragm
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 3 inH₂O
Pressure, Min: 0 inH₂O
Proof Pressure: Up to 10 psi
Supply Voltage: 10 to 35 Vdc
Loop Resistance: 0 to 1250 Ω max
Span Adjustment: Potentiometers
Thermal Effects: ± 0.045% FS/°C
Electrical Output: 4 to 20 mA
Materials, Wetted: Consult Factory
Power Consumption: max 38 mA
Supply Power Type: DC
Dial Outer Diameter: 127 mm
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Additional Features 1: Weatherproof Housing
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 48.9 °C
Operating Temperature, Min: -6.67 °C
Compensated Temperature, Max: 48.9 °C
Compensated Temperature, Min: 0 °C
Material Construction Option: Weatherproof Enclosure
material-construction-option: Weatherproof Enclosure
Zero Setting Adjustable Range: Protected Potentiometers
