Weight: 198 g
Accuracy: ± 0.25 %
Compliance: CE
Display Type: N/A
Accuracy Note: ± 0.25% FS* at room temperature. *RSS includes non-linearity, hysteresis and non-repeatability
Mounting Note: Vertical
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 1 inH₂O
Pressure, Min: -1 inH₂O
Response Time: 10 ms
Proof Pressure: Up to 15 psi
Supply Voltage: 16 to 32 Vdc
Loop Resistance: 0 to 800 Ω max
Thermal Effects: ± 0.01 FS/°F
Electrical Output: 4 to 20 mA
Materials, Wetted: 302 Stainless Steel, Brass, Glass, Nickel, Silicone
Supply Power Type: DC
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Mounting Orientation: 1.378" DIN rail
Thermal Effects Note: (Includes zero and span) ± 0.01 FS/°F, 20 to 170°F (-7 to 77°C).
Electrical Connection: Screw Terminal
Process Connection Note: Barbed fittings ID rubber or vinyl tubing
Process Connection Size: 1/8 in
Process Connection Type: Barbed Fitting
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -54 °C
Operating Temperature, Max: 77 °C
Operating Temperature, Min: -18 °C
Compensated Temperature, Max: 77 °C
Compensated Temperature, Min: -18 °C
Zero Setting Adjustable Range: Potentiometer
