Weight: 0.9 kg
Accuracy: ± 0.25 %
Compliance: FM
Display Type: N/A
Mounting Note: Not Position Sensitive
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 5 inH₂O
Pressure, Min: -5 inH₂O
Response Time: 250 ms
Proof Pressure: Up to 15 psi
Supply Voltage: 12 to 36 Vdc
Compliance Note: FM approved intrinsically safe for use in Class I, Div. 1, Groups A, B, C, D; Class II, Div. 1, Groups E, F, G; Class III, Div. 1 when wired with approved intrinsically safe barrier. Entity parameters: Vmax= 36 VDC; Imax= 250 mA; CI=12 nF; LI=0 mH
Loop Resistance: 0 to 1045 Ω max
Number of Wires: 2
Span Adjustment: Potentiometers
Thermal Effects: ± 0.02% F.S./°F
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP65, NEMA Type 4X
Materials, Wetted: Consult Factory
Supply Power Type: DC
Long Term Stability: ± 0.5% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Electrical Connection: 1/2 in NPT female Conduit with Screw Terminal block
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Operating Temperature, Max: 85 °C
Operating Temperature, Min: -28 °C
Compensated Temperature, Max: 71 °C
Compensated Temperature, Min: -18 °C
Zero Setting Adjustable Range: Potentiometers
