Weight: 397 g
Accuracy: ± 1 %
Materials: Epoxy, Steel
Display Type: N/A
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 3 inH₂O
Pressure, Min: 0 inH₂O
Proof Pressure: Up to 20 psi
Supply Voltage: 18 to 30 Vdc
Loop Resistance: 400Ω @ 18 VDC, 600Ω @ 24 VDC, 1000Ω @ 30 VDC
Number of Wires: 2
Span Adjustment: Adjustable
Thermal Effects: Zero: ± 0.05% FS/°F, Span: ± 0.05% rdg/°F
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP56, NEMA Type 4
Materials, Wetted: Brass, Fluorosilicone, Glass-filled Polyester, Silicone, Vinyl
Supply Power Type: DC
Long Term Stability: ± 1.5% FS output/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Oxygen, Steam
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
Zero Setting Adjustable Range: Adjustable, ± 10%
