Weight: 108 g
Accuracy: ± 0.4 %
Materials: Stainless Steel, PC-ABS
Display Type: N/A
Accuracy Note: ± 0.4% FS* at room temperature. *RSS (Root Sum Square) includes non-linearity, hysteresis and non-repeatability
Output Signal: Current
Pressure Type: Differential
Pressure, Max: 0.5 inH₂O
Pressure, Min: 0 inH₂O
Response Time: 10 ms
Burst Pressure: 30 psi Maximum
Proof Pressure: Up to 15 psi
Supply Voltage: 13 to 32 Vdc
Loop Resistance: 0 to 950 Ω max
Span Adjustment: Potentiometers
Thermal Effects: ± 0.20%FS/°C
Electrical Output: 4 to 20 mA
Materials, Wetted: 302 Stainless Steel, Acrylic, Glass, Nickel, Polyethylene, Silicone
Supply Power Type: DC
Long Term Stability: ± 1% FS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Conductive Gases, Non-Corrosive Dry Gases
Electrical Connection: Screw Terminal
Process Connection Size: 3/16 in
Process Connection Type: Barbed Fitting
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -54 °C
Operating Temperature, Max: 77 °C
Operating Temperature, Min: -18 °C
Zero Setting Adjustable Range: Push Button
