Shock: 200 g
Weight: 65 g
Accuracy: ± 0.25 %
Materials: Stainless Steel, Valox
Stability: 0.5% FS/year
Vibration: 20 g
Accuracy Note: ± 0.25% BFSL (RSS), (includes non-linearity, hysteresis and non repeatability)
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 5 psi
Pressure, Min: 0 psi
Response Time: 5 ms
Proof Pressure: Up to 2000 psi
Supply Voltage: 9 to 30 Vdc
Loop Resistance: 0 to 800 Ω
Number of Wires: 2
Span Adjustment: Fixed
Thermal Effects: Zero: ± 3.6% FS/100°F; Span: ± 2.7% FS/100°F
Materials, Wetted: 17-4 Stainless Steel
Supply Power Type: DC
Media Compatibility: Air, Gases, Nitrogen, Oil, Oxygen, Solvents, Water
Electrical Connection: Cable
Operating Temperature, Max: 185 °F
Operating Temperature, Min: -40 °F
Compensated Temperature, Max: 176 °F
Compensated Temperature, Min: -40 °F
Zero Setting Adjustable Range: Fixed
