Weight: 380 g
Accuracy: ± 0.25 %
Materials: Aluminum
Stability: <0.5% FS/year
Compliance: CE
Accuracy Note: ± .25% FS (includes non-linearity, hysteresis and nonrepeatability)
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 50 psi
Pressure, Min: 0 psi
Burst Pressure: 100 psi Maximum
Supply Voltage: 9 to 30 Vdc
Loop Resistance: 800 Ω
Number of Wires: 2
Span Adjustment: ± 15%, Non-Interactive
Materials, Wetted: 17-4 Stainless Steel
Relative Humidity: 10 to 90% RH, Non-Condensing
Supply Power Type: DC
Media Compatibility: Ammonia, Chlorine, Corrosive Gases, Corrosive Liquids, Hydrochloric Acid, Sulfuric Acid
Electrical Connection: 1/2 NPS female Conduit with Screw Terminal block
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 260 °F
Operating Temperature, Min: -40 °F
Compensated Temperature, Max: 176 °F
Compensated Temperature, Min: -4 °F
Zero Setting Adjustable Range: ± 15%, Non-Interactive
