Shock: 200 g
Weight: 227 g
Accuracy: ± 0.13 %
Vibration: 20 g @ 50 to 2000 Hz
Accuracy Note: ± .13% FS (includes non-linearity, hysteresis and non-repeatability)
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 5000 psi
Pressure, Min: 0 psi
Response Time: 5 ms
Burst Pressure: 100 psi Maximum
Supply Voltage: 9 to 30 Vdc
Loop Resistance: 800 Ω
Number of Wires: 2
Span Adjustment: ± 0.5 mA, Non-Interactive
Thermal Effects: Zero Shift: 1.0% FS/100°F, Span Shift: ± 1.5% FS/100°F
Materials, Wetted: 17-4 Stainless Steel
Relative Humidity: 10 to 90% RH, Non-Condensing
Supply Power Type: DC
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Electrical Connection: Cable
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 260 °F
Operating Temperature, Min: -40 °F
Compensated Temperature, Max: 176 °F
Compensated Temperature, Min: -4 °F
Zero Setting Adjustable Range: ± 0.5 mA, Non-Interactive
