Weight: 46 g
Accuracy: ± 0.5 %
Materials: ABS, Polyamide
Compliance: CE, UKCA
Dial Depth: 28 mm
Sensor Type: Piezoresistive Pressure Sensor
Display Type: N/A
Accuracy Note: ≤ ± 0.5% RSS (BFSL), ± 1 Pa, Accuracy specifications are based on measurements at 73°F (23°C)
Mounting Note: Panel Mount
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 15 inH₂O
Pressure, Min: 0 inH₂O
Response Time: 1 s
Supply Voltage: 18 to 30 Vac/Vdc
Loop Resistance: ≥ 1 kΩ (≤ 10 mA)
Number of Wires: 3
Electrical Output: 0 to 10 V
Enclosure Ratings: IP54
Power Consumption: 40 mA
Relative Humidity: 0 to 95% RH, non-condensing
Supply Power Type: AC/DC
Cable Conduit Type: Cap Nut Conduit
Response Time Note: Default: 1 s, User Selectable: 200 ms
Dial Outer Diameter: 66 mm
Long Term Stability: ≤ ± 1% RSS/year
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Cable Conduit Length: 15 mm
Electrical Connection: Cable Gland with Screw Terminal block
Process Connection Size: 6 mm
Process Connection Type: Barbed Fitting
Cable Conduit Length Note: 15 mm (across flats)
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
