Weight: 4 lb
Accuracy: ± 2 %, ± 5% with transitional flow
Dial Dia: 4 in
Division: 0
Compliance: CE, CSA, UL
Dial Depth: 8.25 in
Switch Note: Each set point has 2 form C relays (DPDT). 10 A @ 28 VDC, 10 A @ 120, 240 VAC
Switch Type: (2) DPDT
Accuracy Note: ± 2% of FS at 70°F (21.1°C). ± 3% on -0 and ± 4% on -00 models
Pressure Type: Differential
Pressure, Max: 150 mmHg
Pressure, Min: 0 mmHg
Repeatability: ± 1%
Switch Rating: 10 A @ 28 Vdc, 10 A @ 120, 240 Vac
Velocity, Min: 0 FPM
Proof Pressure: -20 inHg to 25 psi
Supply Voltage: 120 Vac
Materials, Wetted: Consult Factory
Supply Power Note: 120 VAC, 50/60 Hz; 240 VAC and 24 VAC power optional
Supply Power Type: AC
Dial Outer Diameter: 5 in
Media Compatibility: Air, Argon, Carbon dioxide, Helium, Nitrogen, Non-Corrosive Dry Gases
Mounting Orientation: Vertical Diaphragm
Set Point Adjustment: Adjustable Knobs
Electrical Connection: Screw Terminal
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 120 °F
Operating Temperature, Min: 20 °F
