Filter: 150 μ or better
Weight: 1.16 kg
Accuracy: ± 10 %
Wire Gauge: 18 AWG
Port 1 Size: 1 in
Port 1 Type: NPT Female
Port 2 Size: 1 in
Port 2 Type: NPT Female
Sensor Type: Compatible Liquids
Switch Type: SPDT NO/NC, Selectable
Pressure Type: Gauge
Repeatability: ± 1%
Switch Rating: 0.17A@120Vac,0.08A@240Vac,0.13A@120Vdc,0.06A@240Vdc
Pressure Limits: Up to 400 psi
Sensor Material: Bronze, TFE, Stainless Steel, Fluoroelastomer, ceramic
Repeatability Note: ± 1% max deviation
Mounting Orientation: Horizontal Leads wires up
Pressure Limits Note: 400 psig (27 bar) @ 100°F (38°C)
Electrical Connection: Pigtail Leads
Actuation Set Point, Max: 6 GPM
Actuation Set Point, Min: 1 GPM
Operating Temperature, Max: 200 °F
Operating Temperature, Min: -20 °F
