Weight: 252 g
Accuracy: ± 0.25 %
Compliance: CE, cULus, IS UL-913
Accuracy Note: 0.25% FS
Output Detail: 4 to 20 mA
Output Signal: Current
Pressure Type: Gauge
Pressure, Max: 50 psi
Pressure, Min: 0 psi
Response Time: 50 ms
Burst Pressure: 150 psi Maximum
Proof Pressure: Up to 30 psi
Supply Voltage: 10 to 28 Vdc
Loop Resistance: 0 to 900 Ω max
Thermal Effects: ± 0.02% FS/°F (includes zero and span)
Enclosure Ratings: IP66, NEMA Type 4X
Materials, Wetted: 316 Stainless Steel, 316L Stainless Steel
Power Consumption: 38 mA
Supply Power Type: DC
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Mounting Orientation: Not Position Sensitive
Electrical Connection: Cable
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 176 °F
Operating Temperature, Min: 0 °F
Compensated Temperature, Max: 176 °F
Compensated Temperature, Min: 0 °F
