Weight: 10 g
Materials: Polycarbonate, PTFE
Switch Note: SPST normally open, 40 mA resistive; Cycle life: More than 20 million cycles, Switch Contacts: 18K gold inlay
Switch Type: SPST
Pressure Type: Differential
Pressure, Max: 100 inH₂O
Pressure, Min: 60 inH₂O
Switch Rating: 40 mA
Proof Pressure: Up to 4 psi
Media Compatibility: Consult Factory
Mounting Orientation: Panel Mount
Electrical Connection: Screw Terminal
Operating Voltage Note: AC/DC - 30 V or less with resistive load.
Operating Voltage, Max: 30 Vac/Vdc
Process Connection Note: Smooth port 5/32˝ diameter for 1/8˝ ID tubing
Process Connection Size: 5/32 in
Process Connection Type: Stem
Storage Temperature, Max: 150 °F
Storage Temperature, Min: -46 °F
Operating Temperature, Max: 150 °F
Operating Temperature, Min: 40 °F
