EAST TESTER ET5407A+ Single-channel programmable DC electronic load (200W, 0-180V, 0-30A)

Rated input:

Power: 200W

Input voltage: 0-180V

Input current: 0-30A

Range:

CV mode: 0.1~19.999V, 0.1~180.00V

CC mode: 0~3.000A, 0~30.00A

CR mode: 0.05Ω~4.50kΩ

CP mode: 0~200W

Tran Test

Mode: CC，CV

T1&T2: 0.05s~99.999s

Battery Test:

Discharge mode: CC，CR

Maximum discharge capacity: 9999Ah

Resolution: 1mA，10mA，10mΩ，1Ω

Range of measurement:

Voltage read-back value: 0~19.999V,0 ~180.00V

Current read-back value: 0~3.000A,0~30.00A

Power read-back value: 200W

Scope of protection:

Over Voltage Protection(OV): ＞21V OR ＞185V over voltage protection

Over Current Protection(OC): ＞3.1 or ＞31A over current protection

Over Power Protection(OP): 210W

Over Temperature Protection: 85℃

General technical specifications:

Power supply voltage: 100Vac±10%~240Vac±10%，50/60Hz

Display: LCD segment code screen, backlight adjustable

Operating temperature: 0℃ to 40℃

Storage temperature: -10℃ to 70℃

Relative humidity: < 80%

Interface: standard USB, optional RS232(or 485)

Dimensions: 75mm×155mm×240mm (width×height×depth)

Standard accessories:

Three-core power cord * 1

Power fuse * 2

User manual* 1
