Color: Black
Width: 23.8 mm
Height: 21.5 mm
Length: 23.8 mm
Diameter: 15 mm
IP Rating: IP68, IP69K
Shell Size: 10
Shell Style: Square Flange
Unit Weight: 13 g
Mating Style: Bayonet
REACH - SVHC: Details
Mating Cycles: 250
Cable Diameter: 7 mm
Contact Gender: Pin (Male)
Current Rating: 6 A
Housing Gender: Female
Mounting Angle: Straight
Mounting Style: Panel Mount
Shell Material: Plastic
Contact Plating: Gold
Contact Material: Brass
Termination Style: Solder Pin
Insert Arrangement: 6
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
