Test force: 0.1Kgf(0.98N), 0.2Kgf(1.96N), 0.3Kgf(2.94N), 0.5Kgf(4.90N), 1.0Kgf(9.8N),
2.0Kgf(19.6N), 2.5Kgf(24.5N), 3.0Kgf(29.4N), 5.0Kgf(49.0N)
Hardness scale: HV0.1, HV0.2, HV0.3, HV0.5, HV1, HV2, HV2.5, HV3, HV5
Hardness conversion: HRA, HRB, HRC, HRD, HRF, HV, HK, HBW, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T
Min measuring unit: 0.01µm
Hardness range: 8-2900HV (or8-4000HV)
Magnification: 100X (measurement), 200X (measurement) Both lens can do observe and measurement work directly
Dwell time: 0-99s (1 second per step)
Data output: Test data display on LCD screen, can save to U-flash in Excel format
Test space: 180mmx160mm (HeightxDepth)
Power supply: AC220V±5%, 50-60Hz
Standard: ISO6507, ASTME92, JISZ2244, GB/T4340.2
Overall dimension: 580*240*660mm
Net weight: about 50Kg
Packing size: 800x470x800
Gross weight: 76kg
Standard Accessories：
Main Instrument x 1
USB flash disk x 1
Middle, Large, V shape testing table Each x 1 Power Cord x 1
Vickers hardness block x 2
10×Digital Micro Eyepiece x 1
10X objective lens x 1
Spare Fuses (2A) x 2
20X objective lens x 1
Production certificate x 1
Regulating Screw x 4
Warranty card x 1
Dust cover x 1
Manual book x 1
