Turret: Automatic (motorized switch)
Force loading: Automatic loading-dwell-unloading
Test force: 0.3Kgf(2.94N), 0.5Kgf(4.90N), 1.0Kgf(9.8N), 2.0Kgf(19.6N), 2.5Kgf(24.5N),
3.0Kgf(29.4N), 5.0Kgf(49.0N), 10.0Kgf(98.0N) (can made from 0.2kgf)
Hardness scale: HV0.3, HV0.5, HV1, HV2, HV2.5, HV3, HV5, HV10
Min measuring unit: 0.01µm
Hardness range: 8-2900HV (or8-4000HV)
Eyepiece: 10X digital eyepiece (15X for optional purchase)
Objective: 5X, 10X, 20X, 40X(select any 3 pieces)
Magnification: 50X, 100X, 200X, 400 (select any 3 from them)
Dwell time: 1-99S (1 second per step)
Data output: 8" touchscreen; USB port (can save to U-flash in Excel format)
Test space: 180mmx160mm (HeightxDepth)
Power supply: AC220V+5%, 50-60Hz
Standard: ISO6507, ASTME92, JISZ2244, GB/T4340.2
Size & N/W: 580*240*660mm; 50kg
Packing size & G/W: 800x470x800; 76kg
Standard Accessories
Main Instrument x 1
USB flash disk x1
Middle, Large, V shape testing table Each x 1
Power Cord x 1
Vickers hardness block x 2
10*Digital Micro Eyepiece x 1
Objective lens x 3
Spare Fuses (2A) x 2
Touch screen pen x 1
Production certificate x 1
Regulating Screw x 4
Warranty card x 1
Dust cover x 1
Manual book x 1
Datasheet
