Detector: High-resolution SDD detector
Excitation source: 4-watt miniature integrated X-ray tube, 50kV Max, 200uA Max
Operating temperature: -20 to 50 °C
Measurement time: 30-200 seconds (the test time can be customized by the user))
Sample types: Liquid, solid and powder
Instrument calibration: Automatic calibration upon startup
Element analysis range: From Mg12 to U92 (Magnesium to Uranium)
Analyzable content range: 1ppm- 99.99%
Calibration curve: Platinum, palladium and rhodium precious metals in catalysts
Size: 270mm*320mm*230mm(Length*Width*Height)
Weight: 9.4kg
Display screen (resolution 1280*800): 8-inch, with Win10 operating system
Data transmission: USB Port, Bluetooth, Wi-Fi, GPS
Safety protection: Radiation indicator light, Built-in radiation protection device (automatically cuts off), Software warning
Report formats: Excel, PDF
Accessories and consumables:: Sample cup testing film, Special testing cup for catalysts, Sampling spoon, Special film for the testing window
Instrument configuration
>standard configuration
Pure Cu initialization standard sample
Special sample cup
USB data cable
Power cord
Test film
Instrument factory and calibration report
Warranty card
>Optional configuration
Battery: Continuous operation for eight hours
catalytic standard sample
150 mesh sieves
Application
In waste acquisition, analysis, and processing:
Helps assess precious metal content in waste like used catalytic converters and industrial catalysts, for efficient recycling and pricing.
In precious metal smelters:
Monitors precious metal composition in raw materials and products, ensuring production accuracy and stability.
For quality inspection:
Conducts strict checks on precious - metal - containing products to meet standards.
In analysis and testing centers:
Detects and analyzes precious metal materials comprehensively, providing data for research and industry.
Features
Fast
Non - destructive
Intuitive
No chemical sample preparation required. It can be directly tested with simple operation.
Quantitatively test the contents of platinum, palladium, and rhodium at one time.
The calibration curve has a wide dynamic linear range, covering from ppm to percentage content.
Low operation and maintenance costs
Equipped with a high - definition built - in camera to clearly display the sample part detected by the instrument.
