Dimension: 650mm*610mm*1040mm
Weight: 165Kg
Detector：Next Generation Peltier cooled FSDD Analyzing from Sodium to Uranium(Optional Upgrade to Super FSDD to extend range from Fluorine to Americium )
High-throughput count rate wide linear dynamic range: 1000-1000000cps, including signal enhancement processing module SNE
Digital Pulse Analyzer: 4096 channels,Peak drift is less than 0.5 channel (24 hours)
X-ray tube: High-power long-life-time X-ray tube beryllium window
High-voltage Unit: High precision HV unit with its own voltage overload protection
Sample observation : High-resolution CCD camera
Collimator: Automatic 8-sizes changer
Filter:10-position automatic filter changer
Concentration range: 0.2ppm to 99.99%
Sample chamber: air, vacuum, helium (optional). Built-in high-power vacuum pump
Power requirements：220ACV 50/60HZ
Fully radiation-protected system; radiation <1 μSv/h
Accessory
>Standard Configurations
Silver Calibration standard
XRF Sample cup(Type 1, Type2, Type 3 and Type 4)
USB cable
Power supply cable
Test Mylar(2㎛, 4㎛,6㎛)
Factory Calibration report
Warranty card
CE/ISO/Radiation Certificates
>Optional
Mill machine (S1 single pot, D2 double pot, T3 three pot)
Sample press pellet machine(30ton, 40ton, 60ton)-
Manual-ESI-30T, ESI-40T, ESI-60T,
Automatic: ESI-30S, ESI-40S, ESI-60S,
Drying oven
Fusing bead machine- ESI900(6 molding cups simultaneously)
Electronic scale- 0.0001g precision
Calibration Standard samples
Power stabilizer- 3000 Watts
Key Features
•Analyze everything fast, The direct-excitation beam path makes full use of the X-ray tube
•100 Watts high voltage unit for wide elemental coverage
•Multiple automated tube filters for enhanced sensitivity
•Multi-instrument hardware protection system, and real-time monitoring of the whole process through software, making the instrument work more stable and safer
•Dedicated light element configuration for best analytical performance of elements such as Fluorine, Sodium ,Magnesium, Aluminum and Silicon
•Measure material homogeneity and/or coating thickness
•Auto controlled collimator masks allow analysis of smallest particles within large samples
•HD camera for sample verification
•Core options：
Auto sampler with spinner: 10/12/14 sample cups available with spinner (10 cups)-
The sample spinner is rotated within the chamber during testing, ensuring an overall accurate reading that best characterizes the entire sample.
