Size of Spectrometer: 565mmx385mmx415mm
Size of sample chamber: 465mmx330mmx110mm
Size of Vacuum sample chamber: Φ150mm×75mm
Weight: 48Kg
Element Range: Na11-U92
Analysis content range: 1ppm- 99.99%
Detector: AmpTek high resolution FAST SDD
DPP Analyzer: 4096 Channel DPP analyzer
Excitation Source: 50W X-ray tube
HV unit: 0-50kV
Power supply: 220ACV 50/60HZ
Environment: -10 °C to 35 °C
Standard Accessories
Standard
Ag- Calibration standard
Vacuum pump
Mining Sample cup
USB cable
Power supply cable
Optional:
Mill machine
Sample pressing machine
Drying oven
Fusing bead machine
Balance
Features and benefits
1 Reliable Results You Can Trust
2 Integrated Sample Spinner Rotates the Sample During Measurement, Ensuring Repeatable Results, Even for Non-Uniform Samples such as Powders.
3 Minimization of User Errors: The Analyzer is Easy to Use with a Simple One-Button Start, Intuitive User Interface, and Large Easy-to-Read Display.
4 Low Operating Costs
5 No Expensive Gases such as Helium or Argon are required - Most Measurements can be Made in Ambient Air or a Vacuum.
6 Very Few Consumables are Required and Maintenance Costs are Extremely Low, especially when compared to other methods such as ICP.
7 Rugged and Durable
8 The ore and mineral analyzer is built with rugged, field-proven components and an industrial-grade PC. These features mean that the benchtop XRF ore tester series is rugged enough to be used in the harshest production facilities. EDX9000B mineral analyzers are all backed by a factory warranty. I
9 Fast Quality Control
10 Fast analysis means that our analyzers can be used at any stage of production for quick feedback on material composition and quality.
